| 型号 | A(mm) | B(mm) | 进出液接口 | 溶积 | 固定螺丝 |
| 1/2HP | 98 | 179 | 3/8" | 1 | M10 |
| 1HP | 120 | 215 | 3/8" | 2.2 | |
| 2HP | 131 | 250 | 3/8" | 3 | |
| 3HP | 147 | 265 | 1/2" | 4 | |
| 5HP | 155 | 287 | 1/2" | 6 | |
| 8HP | 180 | 313 | 1/2" | 8 | |
| 10HP | 219 | 313 | 5/8" | 10 | M12 |
| 12HP | 219 | 355 | 5/8" | 12 | |
| 14HP | 219 | 390 | 5/8" | 14 | |
| 16HP | 219 | 450 | 7/8" | 16 | 三角形 |
| 18HP | 219 | 530 | 7/8" | 18 | |
| 20HP | 219 | 600 | 7/8" | 20 |
| 型号 | 外型尺寸(mm) | 进液接口 | 出液接口 | 溶积(L) | |||||||
| A | C | D | E | F | G | H | 配机架 | ||||
| 3HP | 700 | 60 | 159 | 350 | 1/4 | 300 | 250 | 300 | 12 | 12 | 12 |
| 5HP | 800 | 60 | 160 | 480 | 1/4 | 301 | 251 | 300 | 12 | 12 | 14 |
| 8HP | 900 | 100 | 161 | 540 | 1/4 | 302 | 252 | 340 | 16 | 16 | 16 |
| 10HP | 1000 | 101 | 162 | 630 | 1/4 | 303 | 253 | 340 | 16 | 16 | 16 |
| 15HP | 1100 | 102 | 163 | 730 | 1/4 | 304 | 254 | 360 | 19 | 16 | 20 |
| 20HP | 1200 | 103 | 164 | 830 | 1/4 | 305 | 255 | 360 | 19 | 19 | 24 |
